Both the IKA C-MAG HS7 HOT PLATE MAGNETIC STIRRER show normal used wear as can be seen in the pictures and also in the Video, please make sure to check all pictures and Video carefully before comitting to buy.
C-MAG HS 7
Magnetic stirrer with heating and ceramic heating plate which offers excellent chemical resistance.
Powerful motor for stirring quantities of up to 10 l (H2O)
Fixed safety circuit of 550 °C
Hot Top indicator >> hot surface warning to prevent burns!
Exact temperature setting via digital display (LED)
Bushing according to DIN 12878 for connecting a contact thermometer, e.g. ETS-D5, enables precise temperature control
Digital error code display
Elevated control panel for protection against leaking liquids
Technical Data
Number of stirring positions 1
Stirring quantity max. per stirring position (H2O) 10 l
Motor rating output 1.5 W
Direction of rotation left
Speed control scale 0 - 6
Speed range 100 - 1500 rpm
Stirring bar length max. 80 mm
Self-heating of the set-up plate by max. stirring (RT:22°C/duration:1h) 1 +K
Heat output 1000 W
Temperature display set-value LED
Temperature display actual-value LED
Heating temperature range 50 - 500 °C
Heat control Turning knob
Heating rate heating plate 5 K/min
Temperature setting resolution of heating plate 5 K
Connection for ext. temperature sensor ETS-D5
Fixed safety circuit 550 °C
Set-up plate material ceramic
Set-up plate dimensions 180 x 180 mm
Dimensions (W x H x D) 220 x 105 x 335 mm
Weight 5 kg
Permissible ambient temperature 5 - 40 °C
Permissible relative humidity 80 %
Protection class according to DIN EN 60529 IP 21
Voltage 230 / 120 / 100 V
Frequency 50/60 Hz
Power input 1020 W
